CARMIX 5.5XL

The Carmix 5.5XL is a high-capacity self-loading concrete mixer designed for large-scale construction projects requiring reliable on-site concrete production, with a yield of 5m³ per batch.

With increased mixing capacity and powerful off-road performance, the Carmix 5.5XL allows contractors to produce, transport and place concrete directly on site without relying on external batching plants.

The Carmix 5.5XL is built for construction environments where high-volume concrete production is required in remote or demanding job site conditions.

Combining loading, batching, mixing and transport into a single machine, the 5.5XL allows operators to produce concrete directly where it is needed. The integrated loading bucket enables raw materials to be loaded on site, while the rotating mixing drum produces consistent concrete batches ready for immediate placement.

With its robust four-wheel drive system and durable construction, the Carmix 5.5XL is widely used on major infrastructure projects, mining operations and renewable energy developments where productivity and mobility are essential.

Typical Applications

Carmix 5.5XL Self Loading Mixer Working Solar Farms
Large infrastructure construction

Mining and resource sector projects

Renewable energy developments

Remote construction sites

Civil construction projects requiring high-volume concrete production

KEY FEATURES

Carmix 5.5XL Self Loading Mixer

Large-capacity mixing drum

WhatsApp Image 2024-06-06 at 12.42.35_f5afde72.jpg

Self-loading bucket


Four-wheel drive

DSC02102 (1024x768).jpg

Hydraulic  discharge system

TECHNICAL SPECIFICATIONS

Concrete Output

Approx. 5m³ per batch

Drum Capacity

7,800 L mixing drum

Engine

Cummins turbo-diesel QBS 4.5 stage 3A tier III, 4 cylinders 119 KW (161 hp)

Transmission

Hydrostatic transmission with permanent four-wheel drive

Loading Bucket Capacity

800 L hydraulic self-loading bucket

Operating Weight

Approx. 9,000 kg

PROJECT ENVIRONMENTS

The Carmix 5.5XL is designed for projects where larger volumes of concrete must be produced efficiently on site.


These machines are commonly used on infrastructure developments, mining operations and renewable energy projects where access to batching plants may be limited. Producing concrete directly on site reduces transport requirements and improves construction efficiency.


The powerful off-road capability allows operators to move easily across rough terrain while maintaining consistent concrete production.

EQUIP StackedLogo-Yellow

Contact

(02) 4415 9180
0400 365 575
Unit 19, 21 Kangoo Road
Somersby NSW 2250

Need more information about the Carmix 5.5XL?

Speak with our team to learn more about Carmix self-loading concrete mixers and find the right solution for your project.
