Typical Applications
Small construction projects
Utility installation works
Infrastructure maintenance projects
Remote construction sites
Residential construction
KEY FEATURES
Compact self-loading concrete mixer
Integrated loading bucket for batching materials
Reliable hydraulic mixing drum
Excellent mobility for restricted access sites
TECHNICAL SPECIFICATIONS
Concrete Output
Approx. 1 m³ per batch
Drum Capacity
Approx. 1,400 L mixing drum
Engine
Perkins Stage III - Tier 3A 403D-15T Turbo-diesel, Power KW 29 (39 HP) set at 2.800 rpm.
Transmission
Hydrostatic transmission with 4-wheel drive
Loading Bucket Capacity
180 L hydraulic self-loading bucket
Operating Weight
Approx. 2,800 kg
PROJECT ENVIRONMENTS
The Carmix ONE is designed for construction environments where compact equipment and efficient concrete production are required.
It is commonly used on projects where traditional concrete delivery is impractical due to site access limitations or project scale.
Contact
(02) 4415 9180
0400 365 575
Unit 19, 21 Kangoo Road
Somersby NSW 2250
CARMIX ONE
The Carmix One is a compact self-loading concrete mixer designed for small construction projects requiring efficient on-site concrete production. The Carmix One is the smallest unit available with a concrete yield of 1m³ per batch.
Its compact design and simple operation make it ideal for projects where mobility and reliable batching are essential.
The Carmix ONE is engineered to provide efficient concrete production in environments where compact equipment is required.
By combining loading, mixing and transport into a single machine, the Carmix ONE allows contractors to produce concrete directly on site without relying on external batching plants. The integrated loading bucket enables operators to batch aggregates easily, while the mixing drum produces consistent concrete batches ready for placement.
The Carmix ONE is commonly used on smaller construction projects where access may be limited but reliable concrete production is still required.
