Tecop AMK 10.2 Dynamic Penetrometer
The Tecop AMK 10.2 is a dynamic penetrometer designed for in-situ soil testing and geotechnical site investigation.
The system provides reliable measurement of soil resistance and stratification, supporting foundation design and ground assessment.
The Tecop AMK 10.2 dynamic penetrometer is used to evaluate soil properties through controlled dynamic penetration testing.
The system operates by driving a probe into the ground using a standardised hammer weight and drop height. The number of blows required to achieve a set penetration depth is recorded and used to determine soil resistance and stratification.
This method provides a fast and effective way to assess ground conditions on construction sites, supporting geotechnical investigations and foundation design decisions.
The AMK 10.2 is widely used on infrastructure, civil construction and geotechnical projects where accurate soil data is required.
Typical Applications
Geotechnical site investigation
Soil compaction testing
Foundation design assessment
Civil construction projects
Road and infrastructure development
KEY FEATURES
Dynamic penetration testing system
Portable and field-ready design
Reliable measurement of soil resistance
Suitable for a wide range of soil conditions
TECHNICAL SPECIFICATIONS
Hammer Weight
10 kg drop hammer
Drop Height
500 mm
Penetration Measurement
Blows per 100 mm penetration
Rod Diameter
Approx. 20 mm rods
Cone Diameter
Standard cone tip (approx. 60°)
Maximum Testing Depth
Up to 10–15 m depending on soil conditions
PROJECT ENVIRONMENTS
The Tecop AMK 10.2 is designed for construction and geotechnical environments where soil conditions must be assessed quickly and accurately.
It is commonly used on infrastructure and civil projects where understanding ground conditions is critical to foundation design and construction planning.
